Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L

Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L

  • Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L
  • Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L
  • Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L
  • Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L
Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L
Product Details:
Place of Origin: Changzhou Jiangsu China
Brand Name: Treering
Certification: ISO 9001
Model Number: Nl-PT10T
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Plastic warp / Carton /Pallet
Delivery Time: 3-20 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 20pcs per weeks
Contact Now
Detailed Product Description
Accessories: Fittings,valve, Pipes Volum: 10000L
Material: LLDPE, UV Resistant , Food Grade Size: D2250*H2800 Mm
Function: Storing And Saving Water, Rain Water, And Recycling Household Water. Advantage: Unique Rib Design With Various Sizes, Dimensions And Colours
High Light:

rotomould water tanks

,

rotational moulding products

,

10000L Plastic Water Tanks For Aquaculture

PT 10000L Plastic Roto Mold Tanks For Vertical Water Storage And Aquaculture For Liquids Storage





Features:







Desciption of the water tank





PT10000liter Vertival shape Plastic water tank , Made by rotomolding technique .

The rotational molding is a thermoplastic fabrication technique that manufactures hollow products by using

heat and a revolving metal mold. Rotomolded products are seamless, uniform in wall thickness and of

single construction, which eliminates costly fabrication processes and the need for replacement parts.







Advantages :


100% food grade plastic ----helps the water to retain its original characteristic over a period of time.


Half automic roto molded technology ----used to prepare the tanks in one piece so that there are no joints.



This prevents leakage and longevity of the tanks.


Inlet and outlet ports are located of flat surfaces which eliminate possibilities of leakage.


The tanks are available in various colours and are odour and fungus free.




Sepcification







Model





Capacity





Weight





Dimensions





Lid





Fitting





Specific Gravity





PT10000 l





2250 Gallon /10000L





300





2225*2800 mm





650





2″ -4"





1.0 -1.35





All the size sheet for the water tank

Mould Capacity Specification Weight (kg)
PT200 200L

Diameter: 560mm

Caliber :370 mm

Heigh : 900 mm

Plastic thickness :3mm

5.5
PT300 300L Diameter: 720mm Caliber :450 mm Heigh : 920 mm Plastic thickness :3.5mm 10
PT500 500l

Diameter: 850mm

Caliber :450 mm

Heigh : 1100 mm

Plastic thickness :4mm

15
PT800 800L

Diameter: 1000mm

Caliber :450 mm

Heigh : 1270 mm

Plastic thickness :4.5mm

18
PT1000 1000L

Diameter: 1070mm

Caliber :450 mm

Heigh : 1400 mm

Plastic thickness :5mm

25
PT1500 1500L

Diameter: 1210mm

Caliber :450 mm

Heigh : 1530 mm

Plastic thickness :5.5mm

35
PT2000 2000L

Diameter: 1330mm

Caliber :450 mm

Heigh :1700 mm

Plastic thickness :5mm

45
PT3000 3000L

Diameter: 1500mm

Caliber :450 mm

Heigh : 1880 mm

Plastic thickness :6.5mm

70
PT4000 4000L D1700*H2100 mm 100
PT5000 5000L D1820*H2230 mm 120
PT6000 6000L D12030*H2420 mm 160
PT8000 8000L D12030*H3100 mm 200
PT10000 10000L

Diameter: 2250mm

Caliber :650m

Heigh : 2750m

Plastic thickness :12.5

280
PT15000 15000L D2680*H3030 mm 420
PT20000 20000L D2700*H3950 mm 600
PT30000 30000L D3100*H4300 mm 1000
PT4000 40000L D3400*H5000mm 1500
PT50000 50000L D3400*H6500 mm 1750



10000L water tank picture

Large Plastic Water Tanks For Vertical Water Storage And Aquaculture PT 10000L 0

Some application of the Polyethylene bulk water storage tank

PT 5000  Rotomold Plastic water tanks for aquaculture purposes with volume of 5000L



Ladder and the standing , if you are need , please let me know : whatsapp/Wechat/Tel: +86 15051955023

PT 5000  Rotomold Plastic water tanks for aquaculture purposes with volume of 5000L



PT 5000  Rotomold Plastic water tanks for aquaculture purposes with volume of 5000L

Leak testing : accessories have flage , valve ,pipe , flage plate , screw water filled into the tank



PT 5000  Rotomold Plastic water tanks for aquaculture purposes with volume of 5000L
