| Place of Origin: | Changzhou Jiangsu China |
| Brand Name: | Treering |
| Certification: | ISO 9001 |
| Model Number: | NL-FP1208 |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Plastic warp / Carton /Pallet |
| Delivery Time: | 3-20 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 10000 pcs per Month |
| Material: | New Or Recycled PE /PP | Size: | 1200*800*150 Mm |
|---|---|---|---|
| Dynamic Loading: | 1000 ( Fork Capacity) | Static Loading: | 4000kg (Floor Capacity) |
| Type: | Flat Top ,Three Runner ,Smooth ,racking | Entry: | 4 Sides |
| Qty Per Stack: | 27 Pcs | Racking Loading: | Suitable For Racking After Install Steel Bar |
| High Light: | polyethylene plastic skids,hygienic plastic pallets |
||
HDPE Flat top Plastic pallets can be used to support and transport goods, can be lifted using a pallet truck
or forklift truck .
The pallet is made of high -design polyethylene, which won't splinter like wood can, may be wiped clean,
and is resistant to dents and corrosion.
Fork openings on all four sides allow the pallet to be accessed with a pallet truck or forklift truck from any
side .Two or more pallets can be stacked for storage. and Ued on the transport of heavy loads, offering
solid wall thickness and excellent cleaning properties
This pallet may be available in other colors ( Stock color is blue ), allowing different types of loads to be
identified and segregated in a warehouse or stockroom.
Food-safe
Smooth surfaces, easy to clean (colour allows for easy identification of dirt)
Ideal load carrier for heavy duty loads
High resistance to damage
High impact resistance - solid, thick walls
Totally closed - permanently
Dimensionally stable in temperatures ranging from -40 °C to +70 °C
Can be reinforced with enclosed metal (please ask for details, extra cost applies)
Specifications
|
Model
|
NL-P1208 ( Flat top , with three runner) |
|
Dimensions
|
1200*800*150 mm
|
|
Feature
|
Flat top ,Impervious to acids, fats, solvents and odors; free of nails and splinter
|
|
Forklift Entry
|
4-way
|
|
Static Load Capacity
|
4000 kg
|
|
Dynamic Load Capacity
|
1000 kg
|
|
Racking loading capacity
|
1000 kg after install steel bar
|
|
Colour
|
Blue color in stock , Customized any other Color
|
|
Minimum Order
|
20 pcs
|
|
Options
|
Custom Logo
|
|
Industry Applications
|
Clean Room
Food and Beverage
WIP load in manufacturing environments
Medical and dental supplies
Pharmaceuticals
Storage and transportation of chemical waste
Horticulture
Store Display
Pharmaceutical
Warehousing,
Distribution, Retail, Printing, Paper, Petrochemical and Mining industries
|
Noticed , 1208 flat top pallet have 3 difference shape
|
Three runner 1208 flat top pallet
|
Three Runner 1208 flat top pallet - EU stacking pallet
|
Nine foot 1208 flat top pallet
|
 |
|
|
Factory pallet size for your reference :
| Modle | Size(mm) | Weight ( kg ) | Loading ( kg ) | ||
| Dynamic | Static | Rack ( install steel bar | |||
| Single face plastic pallet (Injection technique ) | |||||
|
Pallet (C) ( can install steel Pipe)
|
1200*800*150 | 9.75 | 800 | 4000 | |
| 1200*1000*150 | 12 | 1000 | 4000 | 0.5T-1T | |
| 1100*1100*150 | 12 | 1000 | 4000 | ||
| 1200*1000*150 | 13 | 1000 | 4000 | ||
| 1200*1200*150 | 14.5 | 1000 | 4000 | ||
| 1200*1000*170 | 13.5 | 1000 | 4000 | ||
| 1200*1000*170 | 1000 | 4000 | |||
| 1300*1100*150 | 14.5 | 1000 | 4000 | ||
| 1400*1200*150 | 18 | 1000 | 5000 | ||
|
Pallet (Nine foot )
|
1000*600*140 | 3.55 | 300 | 1000 | 0 |
| 1000*800*140 | 4.5 | 500 | 1000 | 0 | |
| 1000*1000*140 | 5.85 | 500 | 1000 | 0 | |
| 1100*1100*150 | 6.7 | 500 | 1000 | 0 | |
| 1200*800*140 | 5.85 | 500 | 1000 | 0 | |
| 1200*1000*150 | 6.7 | 500 | 1000 | 0 | |
|
Picture Frame Pallet (T)
|
1100*1100*150 | 9 | 800 | 2000 | 0 |
| 12 | 1200 | 3000 | 0 | ||
| 13 | 1500 | 4000 | 0 | ||
| 1200*1000*150 | 9 | 800 | 2000 | 0 | |
| 12 | 1200 | 3000 | 0 | ||
| 1200*800*135 | 10 | ||||
| 1200*1200*150 | 14.75 | 1200 | 5000 | 0 | |
|
Flat Top Pallet (F)
|
1200*1000*150 | 14 | 1000 | 4000 | 1000 |
| 1000*600*150 | 5.5 | ||||
| 1000*800*150 | 7.8 | ||||
| 1000*1000*150 | 9.5 | ||||
| 1200*800*150 | 10.5 | ||||
| 12.5 | 800 | ||||
| 1200*1000*150 | 12 | 1000 | 4000 | ||
|
Floor Pallet (M) |
1000*600*50 | 2.925 | X | 700 | X |
| 2.44 | X | 500 | X | ||
| Modle | Size(mm) | Weight ( kg ) | Loading ( kg ) | ||
| Dynamic | Static | Rack | |||
| Single face pallet - nine foot ( blowing moulding technique ) | |||||
| BM-N1111 | 1100*1100*150 | 10 | 1500 | 4000 | |
| BM-N1210-C | 1200*1000*150 | 7.5 | 1000 | 3000 | |
| BM-N210-B | 1200*1000*150 | 8.5 | 1000 | 4000 | |
| BM-N1210-A | 1200*1000*150 | 10 | 1500 | 4000 | |
| BM-N1212 | 1200*1000*150 | 14 | 1000 | 4000 | |
| Duble face pallet ( blowing moulding technique ) | |||||
| BM -P1111 | 1100*1100*170 | 20kg | 2500 | 6000 | 0 |
| BM -P1210 | 1200*1000*170 | 20kg | 2500 | 6000 | 0 |
| BM -P1311 | 1300*1100*170 | 25kg | 2500 | 6000 | 0 |
| BM -P1212 | 1200*1200*170 | 22kg | 2500 | 6000 | 0 |
| BM -P1412 | 1400*1200*170 | 27kg | 3000 | 6000 | 0 |
| BM -P1512 | 1500*1200*150 | 32kg | 3000 | 6000 | 0 |
| BM -P1513 | 1500*1300*150 | 36kg | 3000 | 6000 | 0 |
| BM -P1614 | 1600*1400*150 | 40kg | 3000 | 6000 | 0 |
Picture Show for Flat Top pallet 1200*1000*150 , surface have Non-slip mat
